Crate Washing Machine

October 24, 2025Admin
crate washing machinecrate washing machine

Main Benefits
  • SUS304 stainless steel for long-lasting hygiene working.
  • Double-layer filtration system to recycle and reduce water use.
  • Adjustable conveyor speed, nozzle angles, and side rails for different trays or crates.
  • High-capacity fan with electric or steam heating for effective drying.
  • Tray or crates clamps and hooks to prevent falling, ensuring safety.
  • Equipped with a viewing window for real-time process monitoring.
  • Designed for easy installation and maintenance with adjustable feet and modular parts.
  • Provides energy-efficient cleaning to save costs and boost productivity.
Category:
Contact Our Specialists

Overview

This food-grade crate washing machine is divided into four sections: a hot alkaline wash, a hot water rinse, a pure water rinse, and an optional air drying section, with disinfection and drying modules customizable as per customer requirements. Made entirely of SUS304 stainless steel (except for bearings), the crate washing machine ensures food safety and corrosion resistance. Crates undergo thorough cleaning in a high-pressure, hot water bath, with circulating spray using horizontal stainless steel centrifugal pumps in each tank. Each tank is equipped with double-pass filters for easy removal of dirt and debris, along with wastewater discharge valves and shutoff pipes. Heating is provided by steam or electric elements, with temperature control adjustable from room temperature to 80°C. The system boasts high capacity, superior oil removal, and fast cleaning cycles. Baskets are conveyed through a high-pressure spray station, rinsed with tap water, and automatically discharged for subsequent use.

Videos

Features

  • Dual-layer filtration system designed for recycling and purifying water in food production
  • Internal hooks to keep the frame securely in place during washing cycles
  • Adjustable conveyor speed (0-15 m/min) to match production line requirements
  • High-power fan for effective drying and ventilation
  • Made from SUS304 stainless steel compliant with food safety standards
  • Highly customized configuration to meet specific process demands
  • Integrated temperature control with optional heating for pasteurization or sterilization
  • Optional heating system for precise thermal processing
  • Customized viewing window for process inspection
  • Optional nozzles for targeted application
  • Spacious water tank supporting continuous operation

Specifications

ModelBWM-3000BWM-4000BWM-5000BWM-6000BWM-8000BWM-10000
Heating MethodElectric /Steam Heating Optional
Voltage(V)220/380/415/440/Customized
Belt Width(mm)300-500/Customized
Belt Speed(m/min)3-15
Transmission Width(mm)400-600/Customized
Heating Power(Kw)24/3624/3636/4836/4836/4836/48
Water Pump Power(Kw)5.55.5*25.5+7.57.5*37.5*37.5*3
Fan Power(Kw)1.50/1.5+1.5+0.751.5+1.5+0.751.5+1.5+0.751.5+1.5+0.751.5+1.5+0.75
Exhaust Power(Kw)0.75*2/Customized
Water Tank Capacity(L)300300500500500500
Weight(Kg)3004006006008001000
Dimension(mm)3000*1400*17004000*1400*17005000*1400*17006000*1400*17008000*1400*170010000*1400*1700

FAQ

How can I ensure the hot water is not overheated and deforms the trays or crates when operating crate washing machine?

Our crate washing machine allows you to set the water tank temperature, steam or electric heating elements in the alkaline and hot water tanks automatically regulate water temperature, adjustable from ambient to 80°C, and once it reaches the set temperature, it stops heating. No worries about overheating the water and damaging the baskets.

What kind of size crates or trays can a crate washing machine clean?

Our crate washing machine can be customized not only to your cleaning process but also to the size of your baskets. It is suitable for all kinds and sizes of food turnover baskets, baskets, milk crates, egg trays, plastic pallets. Just inform us your crate or tray dimension, we can customize suitable crates washing machine for you accordingly.

What is the cleaning process of one crate washer?

Our crates washers typically have four built-in processes: hot alkaline water, hot water, cold water, and air drying.  First, the baskets are cleaned in a high-pressure, hot water bath. Each circulating water tank uses a horizontal stainless steel centrifugal pump for circulating spraying, with the baskets sprayed and rinsed simultaneously from top, bottom, left, and right. Each tank is equipped with a double-pass filter for convenient cleaning of contaminated items. Each tank has a separate wastewater cleaning valve and a shutoff pipe for subsequent discharge. Steam or electric heating elements are installed in the alkaline water tank and the hot water tank, respectively. Our crate washer features a drying area at the end of the process, equipped with a high-powered fan. The fan is mounted on several pipes to ensure thorough drying of the washed baskets. And if you require a different cleaning process, we can also customize your basket washer.

How can we confirm the right crate washing machine for order?

Please let us know what kind of crates, tray, pallets etc you will washing with, dimension of your tray, washing capacity, and condition of the tray or crates, how dirty it is, and what kind of material you process with this tray or crates. Then our specialist and engineer can provide you full free solution and offer quotation.

Why should I order one crate washing machine?

Our crate washing machine typically have four built-in processes: hot alkaline water, hot water, cold water, and air drying. These processes can quickly and efficiently clean large quantities of baskets stained with dirt, blood, oil, and other stains. They also air-dry the baskets immediately after cleaning, ensuring a clean and hygienic environment while saving manpower.

INTERESTING? REACH US TO GET Crate Washing Machine PRICE NOW!
